CAT 424 B2 vs JCB 3DX

CAT 424 B2 vs JCB 3DX – Comparing Specs & Prices

Posted on March 31, 2026March 31, 2026 by admin

Backhoe loaders are the backbone of India’s construction, mining, and infrastructure sectors. Among all brands, CAT and JCB dominate the market — and two of their most popular models, CAT 424 B2 and JCB 3DX, are often compared head‑to‑head.

If you’re planning to buy a backhoe loader for earthmoving, roadwork, or general construction, this detailed, specification‑by‑specification comparison will help you choose the right machine for your project scale, terrain, and operating conditions.

⭐Price Comparison

Model Variant Ex‑Showroom Price
CAT 424 B2 Base ₹34.00 Lakh
JCB 3DX Base ₹35.00 Lakh

The prices listed — ₹34–35 lakh for CAT 424 B2 and ₹35–38 lakh for JCB 3DX — are Indian ex-showroom prices. These figures are based on comparisons from Indian construction equipment portals and reflect the cost in India, not the USA.

In the U.S., pricing would differ significantly due to:

  • Import duties and taxes
  • Different engine compliance standards (EPA Tier vs Bharat Stage)
  • Optional features and attachments
  • Dealer location and freight costs

🔥Engine Specifications Comparison

Specification CAT 424 B2 JCB 3DX
Engine Model KOEL / 4R‑1040T JCB 448
Displacement 4160 cc NA
Gross Power 76 HP 49 HP @ 2000 RPM

🏗️Loader Performance Comparison

Parameter CAT 424 B2 JCB 3DX
Dump Height 2632 mm 2740 mm
Load Over Height NA 3320 mm
Hinge Pin Height 3323 mm 3540 mm
Bucket Capacity 1.1 m³ 1.1 m³

⛏️Backhoe Performance Comparison

Parameter CAT 424 B2 JCB 3DX
Max Dig Depth 4773 mm 4770 mm
Bucket Rotation 205° 185°
Max Lift Capacity 2642 kg 1490 kg

⚙️Dimensions & Operating Weight

Parameter CAT 424 B2 JCB 3DX
Operating Weight 7911 kg 7510 kg
Transport Length 5698 mm 5900 mm
Ground Clearance 396 mm 310 mm

💧Hydraulic System Comparison

Parameter CAT 424 B2 JCB 3DX
Pump Type Variable Flow Axial‑Piston NA
Pump Flow 115 lpm 114 lpm

🛢️Service Capacities Comparison

Capacity CAT 424 B2 JCB 3DX
Engine Oil 12 L NA
Rear Axle 17 L 20 L
Hydraulic Oil 38 L 110 L

🛞Comparing Tyres

Tyre Type CAT 424 B2 JCB 3DX
Front 9×16 – 16 PR 9×16 – 16 PR
Rear 16.9×28 – 12 PR 16.9×28 – 12 PR

🛑Braking Systems Comparison

Parameter CAT 424 B2 JCB 3DX
Service Brakes Hydraulic Multi‑Disc JCB ‘Q’ Brakes, Oil‑Immersed
Parking Brake NA Hand‑Operated Disc Brake

🔄Steering Comparison

Parameter CAT 424 B2 JCB 3DX
Type Fully hydrostatic Power assisted
Turning Circle (Outside Bucket) NA 11600 mm
Turning Circle (Not Braked) 10.8 m 8640 mm
System Pressure 235 bar NA

Final Verdict: Which One Should You Buy?

Choose CAT 424 B2 if you want:

  • Higher engine power (76 HP)
  • Better lifting capacity
  • Higher ground clearance
  • Closed‑centre hydraulic system
  • Heavy‑duty stability

Choose JCB 3DX if you want:

  • Better loader reach & breakout force
  • Larger backhoe bucket options
  • Superior braking system
  • Tighter turning radius
  • Strong resale value & widespread service network
